CAD Project
Nusle Brewery

LOCATION

Prague

Czech Republic

Time spent

14 Days on site

90 Dossier processing days

products

Pointcloud, 360° Photo Viewer, CAD Documentation

accuracy

2mm Pointcloud

20mm CAD Documentation

CAD Project: Nusle Brewery

The former brewery in Nusle (Prague) founded in 1694 was the largest industrial brewery in Central Europe. At the time of surveying, there were many companies in the complex and the measurements had to be carried out without interrupting the leased buildings. The surveying of all buildings with a total area of over 100 000 m2 was done in just 14 days.
We achieved great speed and accuracy (2 mm) by using state-of-the-art technologies and techniques, such as ground and aerial photogrammetry combined with 3D laser scanning, LIDAR and conventional geodetic methods. The output was 2D documentation (floor plans, sections, elevations).

“A complete survey of the current condition of the Nusle Brewery complex was carried out very quickly and was of high quality, despite the fact that it is a very complicated structure of considerable size. The resulting documentation of the buildings fulfilled our expectations and the agreed deadline was met.”
